Research data management
👩‍💻👨‍💻
with DataLad

Adina Wagner mas.to/@adswa
	Psychoinformatics lab, Institute of Neuroscience and Medicine (INM-7) Research Center Jülich

Welcome & Logistics!

• A approximate schedule for today:
  • 1.00 pm: Introduction & Logistics
  • 1.30 pm: Overview of DataLad + break ☕
  • 2.00 pm: What's version control, and why should I care?
  • 2:45 pm: Reproducibility features + break
  • 3.30 pm: Data publication to the OSF + break ☕
  • 4.30 pm: Outlook and/or Your Questions and Usecases
• Collaborative notes & anonymous questions: etherpad.wikimedia.org/p/Datalad@sfb1280.
• Slides are CC-BY and will be shared after the workshop. Additional workshop contents: psychoinformatics-de.github.io/rdm-course
• Some guidelines for the virtual workshop venue...
• Please mute yourself when you don't speak
• Ask questions anytime, but make use of the "Raise hand" feature
• Drop out and re-join as you please

Questions/interaction throughout the workshop

• There are no stupid questions :)
• Lively discussions are wonderful - unless its interrupting others, please feel encouraged to unmute/turn on your video to interact.
• There is room discuss specific or advanced use cases at the end. Please make a note about them in the Etherpad.

Questions/interaction after the workshop

If you have a question after the workshop, you can reach out for help:

Reach out to to the DataLad team via
• Matrix (free, decentralized communication app, no app needed). We run a weekly Zoom office hour (Tuesday, 4pm Berlin time) from this room as well.
• the development repository on GitHub


Reach out to the user community with
• A question on neurostars.org with a datalad tag


Find more user tutorials or workshop recordings
• On DataLad's YouTube channel
• In the DataLad Handbook
• In the DataLad RDM course
• In the Official API documentation

Resources and Further Reading

Comprehensive user documentation in the DataLad Handbook (handbook.datalad.org)

	High-level function/command overviews, Installation, Configuration, Cheatsheet
	Narrative-based code-along course Independent on background/skill level, suitable for data management novices
	Step-by-step solutions to common data management problems, like how to make a reproducible paper

Overview of most tutorials, talks, videos, ... at github.com/datalad/tutorials

Live polling system

What's your mood today?

Practical aspects

• We'll work in the browser on a cloud server with JupyterHub
• Cloud-computing environment:
     - datalad-hub.inm7.de
• We have pre-installed DataLad and other requirements
• We will work via the terminal
• Your username is all lower-case and follows this pattern: Firstname + Lastname initial (Adina Wagner -> adinaw)
• Pick any password with at least 8 characters at first log-in (and remember it)

Please try to log in now

Prerequisites: Using DataLad

• Every DataLad command consists of a main command followed by a sub-command. The main and the sub-command can have options.
• Example (main command, subcommand, several subcommand options):

  $ datalad save -m "Saving changes" --recursive

• Use --help to find out more about any (sub)command and its options, including detailed description and examples (q to close). Use -h to get a short overview of all options

  $ datalad save -h
        Usage: datalad save [-h] [-m MESSAGE] [-d DATASET] [-t ID] [-r] [-R LEVELS]
                      [-u] [-F MESSAGE_FILE] [--to-git] [-J NJOBS] [--amend]
                      [--version]
                      [PATH ...]

  Use '--help' to get more comprehensive information.


Using DataLad in the Terminal


            datalad --version






              datalad --help




                datalad wtf -S system



git identity


          git config --get user.name
          git config --get user.email




          git config --global user.name "Adina Wagner"
          git config --global user.email "adina.wagner@t-online.de"




          git config --global --add datalad.extensions.load next



Using datalad via its Python API


            ipython




              import datalad.api as dl
              dl.create(path='mydataset')




              exit



Different ways to use DataLad

DataLad can be used from the command line

datalad create mydataset

... or with its Python API

import datalad.api as dl
dl.create(path="mydataset")

... and other programming languages can use it via system call

# in R
> system("datalad create mydataset")

• ... or via a graphical user interface "DataLad Gooey"

Acknowledgements

Software Joey Hess (git-annex) The DataLad team & contributors Illustrations The Turing Way project & Scriberia

Funders Collaborators

Core Features:

• Joint version control (Git, git-annex): version control data & software alongside your code
• Provenance capture: Create and share machine-readable, re-executable provenance records for reproducible, transparent, and FAIR research
• Decentral data transport mechanisms: Install, share and collaborate on scientific projects; publish, update, and retrieve their contents in a streamlined fashion on demand, and distribute files in a decentral network on the services or infrastructures of your choice

Examples of what DataLad can be used for:

• Publish or consume datasets via GitHub, GitLab, OSF, the European Open Science Cloud, or similar services

Examples of what DataLad can be used for:

• Behind-the-scenes infrastructure component for data transport and versioning (e.g., used by OpenNeuro, brainlife.io , the Canadian Open Neuroscience Platform (CONP), CBRAIN)

Examples of what DataLad can be used for:

• Creating and sharing reproducible, open science: Sharing data, software, code, and provenance

Examples of what DataLad can be used for:

• Creating and sharing reproducible, open science: Sharing data, software, code, and provenance

Examples of what DataLad can be used for:

• Central data management and archival system

Examples of what DataLad can be used for:

• Scalable computing framework for reproducible science

What's version control, and why should I care?

Everything happens in DataLad datasets

Look and feel like a directory on your computer content agnostic no custom data structures Terminal view

File viewer

...Datalad datasets


            datalad create -c text2git my-analysis




                cd my-analysis




                ls -la .



Dataset = Git/git-annex repository

Stay flexible:

• Non-complex DataLad core API (easy for data management novices)
• Pure Git or git-annex commands (for regular Git or git-annex users, or to use specific functionality)

...Version control


            echo "# My example DataLad dataset" > README.md




                datalad status




                datalad save -m "Create a short README"




                echo "This dataset contains a toy data analysis" >> README.md




                git diff




                datalad save -m "Add information on the dataset contents to the README"



...Version control


                git log




                tig

            (navigate with arrow keys and enter, press "q" to go back and exit the program)


Exhaustive tracking

The building blocks of a scientific result are rarely static

Analysis code evolves (Fix bugs, add functions, refactor, ...)

Based on Piled Higher and Deeper 1531

Exhaustive tracking

The building blocks of a scientific result are rarely static

Data changes (errors are fixed, data is extended, naming standards change, an analysis requires only a subset of your data...)

Piled Higher and Deeper 1323

Exhaustive tracking

The building blocks of a scientific result are rarely static

Data changes (for real) (errors are fixed, data is extended, naming standards change, ...)

Exhaustive tracking

Exhaustive tracking

Exhaustive tracking

            datalad containers-add nilearn \
     --url shub://adswa/nilearn-container:latest




                datalad containers-list



Digital provenance

= "The tools and processes used to create a digital file, the responsible entity, and when and where the process events occurred"

• Have you ever saved a PDF to read later onto your computer, but forgot where you got it from? Or did you ever find a figure in your project, but forgot which analysis step produced it?

Digital provenance

            wget -P code/ \
   https://raw.githubusercontent.com/datalad-handbook/resources/master/get_brainmask.py




                datalad status




                 datalad save -m "Adding a nilearn-based script for brain masking"



            datalad download-url -m "Add a tutorial on nilearn" \
   -O code/nilearn-tutorial.pdf \
   https://raw.githubusercontent.com/datalad-handbook/resources/master/nilearn-tutorial.pdf




                datalad status



            git log code/nilearn-tutorial.pdf


Provenance and reproducibility

Provenance and reproducibility

... Computationally reproducible execution I

            black code/get_brainmask.py


            git diff


            git restore code/get_brainmask.py


            datalad run -m "Reformat code with black" \
 "black code/get_brainmask.py"


            git show


            datalad rerun


Seamless dataset nesting & linkage

Seamless dataset nesting & linkage

$ datalad clone --dataset . http://example.com/ds inputs/rawdata


$ git diff HEAD~1
diff --git a/.gitmodules b/.gitmodules
new file mode 100644
index 0000000..c3370ba
--- /dev/null
+++ b/.gitmodules
@@ -0,0 +1,3 @@
+[submodule "inputs/rawdata"]
+       path = inputs/rawdata
+       datalad-id = 68bdb3f3-eafa-4a48-bddd-31e94e8b8242
+       datalad-url = http://example.com/importantds
diff --git a/inputs/rawdata b/inputs/rawdata
new file mode 160000
index 0000000..fabf852
--- /dev/null
+++ b/inputs/rawdata
@@ -0,0 +1 @@
+Subproject commit fabf8521130a13986bd6493cb33a70e580ce8572


...Dataset nesting

            datalad clone -d . \
 https://gin.g-node.org/adswa/bids-data \
 input



                datalad subdatasets




                git show



...Computationally reproducible execution...

cd ..
datalad run -m "Compute brain mask" \
  --input input/sub-02/func/sub-02_task-oneback_run-01_bold.nii.gz \
  --output "figures/*" \
  --output "sub-02*" \
  "python code/get_brainmask.py"

• Software can be difficult or impossible to install (e.g. conflicts with existing software, or on HPC) for you or your collaborators
• Different software versions/operating systems can produce different results: Glatard et al., doi.org/10.3389/fninf.2015.00012
• Software containers encapsulate a software environment and isolate it from a surrounding operating system. Two common solutions: Docker, Singularity

Software containers

Computational provenance

• The datalad-container extension gives DataLad commands to register software containers as "just another file" to your dataset, and datalad containers-run analysis inside the container, capturing software as additional provenance

...Computationally reproducible execution


datalad containers-run -m "Compute brain mask" \
     -n nilearn \
     --input input/sub-02/func/sub-02_task-oneback_run-01_bold.nii.gz \
     --output "figures/*" \
     --output "sub-02*" \
     "python code/get_brainmask.py"




                git log sub-02_brain-mask.nii.gz




                datalad rerun



Sharing datasets

Sharing datasets

Transport logistics: Lots of data, little disk-usage

• Cloned datasets are lean. "Meta data" (file names, availability) are present, but no file content:

$ datalad clone git@github.com:psychoinformatics-de/studyforrest-data-phase2.git
  install(ok): /tmp/studyforrest-data-phase2 (dataset)
$ cd studyforrest-data-phase2 && du -sh
  18M	.

• files' contents can be retrieved on demand:

$ datalad get sub-01/ses-movie/func/sub-01_ses-movie_task-movie_run-1_bold.nii.gz
  get(ok): /tmp/studyforrest-data-phase2/sub-01/ses-movie/func/sub-01_ses-movie_task-movie_run-1_bold.nii.gz (file) [from mddatasrc...]

# eNKI dataset (1.5TB, 34k files):
$ du -sh
1.5G	.
# HCP dataset (~200TB, >15 million files)
$ du -sh
48G	.

There are two version control tools at work - why?

Git does not handle large files well.

There are two version control tools at work - why?

Git does not handle large files well.

And repository hosting services refuse to handle large files:

git-annex to the rescue! Let's take a look how it works

Git versus Git-annex

Dataset internals

• Where the filesystem allows it, annexed files are symlinks:

  $ ls -l sub-02/func/sub-02_task-oneback_run-01_bold.nii.gz
  lrwxrwxrwx 1 adina adina 142 Jul 22 19:45 sub-02/func/sub-02_task-oneback_run-01_bold.nii.gz ->
  ../../.git/annex/objects/kZ/K5/MD5E-s24180157--aeb0e5f2e2d5fe4ade97117a8cc5232f.nii.gz/MD5E-s24180157
  --aeb0e5f2e2d5fe4ade97117a8cc5232f.nii.gz


  (PS: especially useful in datasets with many identical files)
• The symlink reveals this internal data organization based on identity hash:

  $ md5sum sub-02/func/sub-02_task-oneback_run-01_bold.nii.gz
  aeb0e5f2e2d5fe4ade97117a8cc5232f  sub-02/func/sub-02_task-oneback_run-01_bold.nii.gz


• The (tiny) symlink instead of the (potentially large) file content is committed - version controlling precise file identity without checking contents into Git
• File contents can be shared via almost all standard infrastructure. File availability information is a decentral network. A file can exist in multiple different locations.

$ git annex whereis code/nilearn-tutorial.pdf
whereis code/nilearn-tutorial.pdf (2 copies)
        cf13d535-b47c-5df6-8590-0793cb08a90a -- [datalad]
        e763ba60-7614-4b3f-891d-82f2488ea95a -- jovyan@jupyter-adswa:~/my-analysis [here]

  datalad: https://raw.githubusercontent.com/datalad-handbook/resources/master/nilearn-tutorial.pdf

Delineation and advantages of decentral versus central RDM: Hanke et al., (2021). In defense of decentralized research data management

Git versus Git-annex

Data in datasets is either stored in Git or git-annex

By default, everything is annexed.

Two consequences: Annexed contents are not available right after cloning, only content identity and availability information (as they are stored in Git). Everything that is annexed needs to be retrieved with datalad get from whereever it is stored. Files stored in Git are modifiable, annexed files are protected against accidental modifcations

Git	git-annex
handles small files well (text, code)	handles all types and sizes of files well
file contents are in the Git history and will be shared upon git/datalad push	file contents are in the annex. Not necessarily shared
Shared with every dataset clone	Can be kept private on a per-file level when sharing the dataset
Useful: Small, non-binary, frequently modified, need-to-be-accessible (DUA, README) files	Useful: Large files, private files

Useful background information for demo later. Read this handbook chapter for details

Git versus Git-annex

Users can decide which files are annexed:


• Pre-made run-procedures, provided by DataLad (e.g., text2git, yoda) or created and shared by users (Tutorial)
• Self-made configurations in .gitattributes (e.g., based on file type, file/path name, size, ...; rules and examples )
• Per-command basis (e.g., via datalad save --to-git)

Publishing datasets

Glossary

Sibling (remote)

Linked clones of a dataset. You can usually update (from) siblings to keep all your siblings in sync (e.g., ongoing data acquisition stored on experiment compute and backed up on cluster and external hard-drive)

Repository hosting service

Webservices to host Git repositories, such as GitHub, GitLab, Bitbucket, Gin, ...

Third-party storage

Infrastructure (private/commercial/free/...) that can host data. A "special remote" protocol is used to publish or pull data to and from it

Publishing datasets

Pushing dataset contents (Git and/or annex) to a sibling using datalad push

Updating datasets

Pulling new changes from a sibling using datalad update --merge

Publishing datasets

• Most public datasets separate content in Git versus git-annex behind the scenes

Publishing datasets

Publishing datasets

Publishing datasets

• Datasets are exposed via a private or public repository on a repository hosting service
• Data can't be stored in the repository hosting service, but can be kept in almost any third party storage
• Publication dependencies automate pushing to the correct place, e.g.,


  $ git config --local remote.github.datalad-publish-depends gdrive
  # or
  $ datalad siblings add --name origin --url git@git.jugit.fzj.de:adswa/experiment-data.git --publish-depends s3



Publishing datasets

Special case 1: repositories with annex support

Publishing datasets

Special case 2: Special remotes with repositories

Publishing to OSF

https://osf.io/

Prerequisites:
1. Log into OSF
2. Create personal access token
3. Enter credentials using datalad osf-credentials:


                datalad osf-credentials



Summary and Take-Home Messages

Your Questions and Usecases

Post-Workshop Contact

• Slides are CC-BY. They will stay online and will be made available as a PDF as well
• Contact the DataLad Team anytime via GitHub issue, Matrix chat message, or in our office hour video call
• Find more DataLad content and tutorials at handbook.datalad.org


• Join us at our first conference for distributed data management: distribits.live (April 2024, registration closes October 15th)

Thanks for you attention!

List of installed software on Jupyter

• apt: Git, git-annex, tree, tig, zsh, singularity
• pip: datalad, datalad-next, datalad-container, datalad-osf, black

Outlook

FAIRly big setup

Exhaustive tracking
• datalad-ukbiobank extension downloads, transforms & track the evolution of the complete data release in DataLad datasets
• Native and BIDSified data layout (at no additional disk space usage)
• Structured in 42k individual datasets, combined to one superdataset
• Containerized pipeline in a software container
• Link input data & computational pipeline as dependencies

FAIRly big workflow

portability
• Parallel processing: 1 job = 1 subject (number of concurrent jobs capped at the capacity of the compute cluster)
• Each job is computed in a ephemeral (short-lived) dataset clone, results are pushed back: Ensure exhaustive tracking & portability during computation
• Content-agnostic persistent (encrypted) storage (minimizing storage and inodes)
• Common data representation in secure environments

FAIRly big provenance capture

Provenance
• Every single pipeline execution is tracked
• Execution in ephemeral workspaces ensures results individually reproducible without HPC access
